Tesla Model S Drive Unit Rear SPORT KIT
Regular price €9.999,00
Article number: 2000760018
The Small Tesla Drive Unit Front Kit is one of our most popular. The small and compact overall package convinces with a very good "power-to-weight ratio". If you're short on space or need a little more efficiency, then the smaller versions of the Tesla drive units are for you. The engines are recycled from Tesla vehicles that have crashed. Of course, the unit remained intact. After purchase, they are refurbished, reprogrammed and fully tested by us.
All Tesla drive units that we offer are supplied as a complete kit. This includes:
- Tesla Model S Sport Drive Unit Rear
- Display touch encoder
- ESDI EV control unit
- ESDI EV board
Technical specifications:
| Characteristic | value |
| HV voltage range |
240 - 404V |
| HV current (peak) |
950A DC |
| LV voltage |
10.5-16VDC |
| LV input current |
< 5A (max) |
| power (peak) |
400 kW (544 hp) |
| torque | 600 Nm |
| engine speed (max.) |
15,200 rpm |
| transmission | Single gear, 9.73:1 open differential |
| cooling | Liquid-cooled, 3/4" connections (flow required during operation) |
| gears | Forward, Neutral, Reverse (No mechanical gear changes. Reverse is achieved by reversing the direction of engine rotation) |
Download: data sheet
Preparation of a Tesla Drive Unit
